| 加工定制：是 | 品牌：◆诸城 | 型号：UDFH-23 |
| 类型：层压太阳能电池板/组件 | 最大功率：320W | 工作电流：10.2A |
| 工作电压：36V | 系统电压：光伏发电板厂家V | 开路电压：日照多晶硅发电板V |
| 短路电流：太阳能发电板A | 电池数量：72个,只 | 外形尺寸：1640x992x40mm |
| 参考重量：18.5KG | 产品认证：CE |
标准测试条件(STC):辐照度1000W/㎡,电池温度25℃，光谱分布AM1.5 | ||||||||
大额定功率(P) | 50W | 80W | 100W | 120W | 150W | 200W | 250W | 300W |
大电压(Vmpp) | 18 | 18 | 18.5 | 17.5 | 18.2 | 37 | 31.1 | 36.9 |
开路电压(Voc) | 22.1 | 22.3 | 22.5 | 22.1 | 22.6 | 45.4 | 37.1 | 45.6 |
大电流(Impp) | 2.78 | 4.44 | 5.4 | 7.42 | 8.24 | 5.41 | 8.16 | 8.12 |
短路电流(Isc) | 3 | 4.8 | 5.84 | 8.01 | 8.92 | 5.76 | 9.12 | 8.62 |
功率温度系数(αP) | -0.49%/K | -0.49%/K | -0.49%/K | -0.49%/K | -0.49%/K | -0.49%/K | -0.49%/K | -1.49%/k |
开路电压温度系数(αVoc) | -0.34%/K | -0.34%/K | -0.34%/K | -0.34%/K | -0.34%/K | -0.34%/K | -0.34%/k | -0.34%/k |
短路电流温度系数(αIsc) | +0.03%/K | +0.03%/K | +0.03%/K | +0.03%/K | +0.03%/K | +0.03%/K | +0.03%/k | +0.03%/k |
额定电池工作温度(NOCT) | 46±3℃ | 46±3℃ | 46±3℃ | 46±3℃ | 46±3℃ | 46±3℃ | 46±3℃ | 46±3℃ |
机械尺寸（MM） | 700*510*30 | 1000*510*30 | 1200*540*30 | 1200*680*35 | 1480*680*35 | 1580*808*35 | 1640*992*40 | 1956*991*45 |
所采用的单晶硅多晶硅太阳能电池片转换效***，输出功率范围是制造公差的±3%
